Automatic Coffee Powder Bottle Filling Capping Sealing And Labeling Line

Application:

Suitable for automatic weighing filling capping and labeling of various fluidic or low-fluidity powder materials like coffee powder, collagen powder, nutrition powder, milk powder, protein powder, cocoa powder, flour, etc. It's widely used in the various industry including pharmaceutical, foodstuff, cosmetic and chemical.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1.Automatic two-head Auger type metering/filling system works with the automatic capping machine.

2.Filling with weighing and rejrct, which can improve the accuracy of filling weight and is suitable for high-value products.

3.Conveyor is mounted a precision splitter to perform the intermittent movement for bottle/can to achieve the accurate positioning function.

4.Transmission system of the filling machine is driven by Japan Panasonic servo motor for high accuracy and stability.

5.Auto bottle/can positioning, lifting and vibrating, filling system is able to stop filling automatically when there's no bottle, and when bottle jammed occurs, the machine (system) will also stop automatically.

6.10 sets of memory modules for memorizing different kinds of products and filling weights.

7.HMI touch screen for operational control.

8.Full automatic solution, to realize feeding, weighing, filling,servo capping,foil sealing, labeling.

9.Available to connect with material supply system at pre-section for auto linking connection.

10.Servo capping machine, adjustable torque, can be screwed tighter.

Application:

Suitable for automatic weighing filling capping and labeling of various fluidic or low-fluidity powder materials like coffee powder, collagen powder, nutrition powder, milk powder, protein powder, cocoa powder, flour, etc. It's widely used in the various industry including pharmaceutical, foodstuff, cosmetic and chemical.

Videos Introduction:

Specification:

Automatic Powder Weighing Filling Capping And Labeling Machine (LF-PJ-W02)
Model	(LF-PJ-W02	LFP-02
Filling Weight	10-5000g(customizable)	10-5000g(customizable)
Bottle diameter	Φ30-Φ140mm(customizable)	Φ30-Φ140mm(customizable)
Bottle height	50mm-200mm(customizable)	50mm-200mm(customizable)
Yield	10-20 Bottle/min	20-40 Bottle/min
Measurement accuracy	≤500g，≤±1%；＞500g，≤±0.5% (Varies due to the characteristics of the material)	≤500g，≤±1%；＞500g，≤±0.5% (Varies due to the characteristics of the material)
Power	2.5KW	5KW
Silo capacity	50L	50L
Power Supply	220V、50Hz	220V、50Hz
Working Pressure	0.6-0.8MPa	0.6-0.8MPa
Weight	350kg	550kg

Optional:

1.Automatic powder weighing filling, equipped with vacuum feeder;

2.Weighing filling;

3.Automatic bottle capping;

4.Automatic bottle sealing;

5.Automatic bottle labeling;

6.Finished product collecting.
