Full automatic coffee powder weighing and filling machine

Application:

This machiine is suitable for filling fluidic or low-fluidity powder material like milk powder, coffee powder, granule additive,etc.

Details:

Model:LF-PJ-02

Brand:Landpack

Height: W：50-200mm

Filling range: 10-5000g

Filling speed:10-20 bottle/min（speed is determined by the product filling quantity）

Average precision:≤ ±1%

Total power:2.5KW

Feature:

Automatic two-head Auger type metering/filling system works with the automatic capping machine.

Able to work with the double star wheels for bottle/can conveying & positioning system to perform the filling operation.

Conveyor is mounted a precision splitter to perform the intermittent movement for bottle/can to achieve the accurate positioning function.

Transmission system of the filling machine is driven by Japan Panasonic servo motor for high accuracy and stability.

Auto bottle/can positioning, lifting and vibrating, filling system is able to stop filling automatically when there's no bottle, and when bottle jammed occurs, the machine (system) will also stop automatically.

10 sets of memory modules for memorizing different kinds of products and filling weights.

HMI touch screen for operational control.

Japan Panasonic PLC.

Available to connect with material supply system at pre-section for auto linking connection.

Available to link with the capping and labeling systems... etc. at post section.

Application:

It is suitable for many kinds of powder products, such as 3 in 1 coffee powder, chili powder, milk tea powder, pharmaceutical powder, herb powder, dry powder, vibro cinnamon powder, flour.

Videos Introduction:

Specification:

Model	LF-PJ-02	LFP-02
Filling Weight	10-5000g (customizable)	10-5000g (customizable)
Bottle diameter	Φ30-Φ140mm (customizable)	Φ30-Φ140mm (customizable)
Bottle height	50mm-200mm (customizable)	50mm-200mm (customizable)
Yield	10-20 Bottle/min	20-40 Bottle/min
Measurement accuracy	≤500g，≤±1%；＞500g，≤±0.5% (Varies due to the characteristics of the material)	≤500g，≤±1%；＞500g，≤±0.5% (Varies due to the characteristics of the material)
Power	2.5KW	5KW
Silo capacity	50L	50L
Power Supply	220V、50Hz	220V、50Hz
Working Pressure	0.6-0.8MPa	0.6-0.8MPa
Weight	350kg	550kg

Advantages:

This powder filling system is driven by a servo motor to ensure high filling accuracy. It is controlled by PLC, man-machine interface and easy to operate. The filling volume can be changed by replacing the screw gauge, and the measuring range is wide.
