Automatic Frozen Food Vacuum Premade Pouch Packing Machine

Application:

This machine is suitable for all kinds of the premade bags, such as pillow bag, 3-side, 4-side and 8-side quad seal bags (box pouch), kraft bags and spout bags and so on,which can pack different items, such as grain, coffee bean, sugar, powder.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

1. Equipped with different metering devices, it can realize packing different material such as powder, liquid, granule, sauce etc.

2 .Various bag type, it is very easy to change.

3. Simple in structure, easy to operate.

4. Sealings with hot seal and cold sealing with smooth sealing effect.

5. No bag open , no fill and seal to save premade bags.

6.Hang hole cutting and top spout adding are optional.
Application:

1. Any product that can pack in bag, such as fish, poultry, meat, grains and other food items.

2. Solid species: candy, peanut, green bean, pistachio, crystal candy, brown sugar, cookie, cake, daily commodities, cooked food, pickles, puffed food, etc.

3. Granule species: grain, refined monosodium glutamate, granular drug, capsule, seed, condiment, granulated sugar, chicken essence, melon seeds, nuts, pesticide, fertilizer, feed etc.

4. Liquid species: detergent, fruit juice, miller wine, soy sauce, vinegar, drinks etc.

5. Thick liquid species: chilli sauce, tomato sauce, peanut butter, jam, bean sauce etc.

Videos Introduction:
Specification:
Model
LG1-430A
Bag Material
Multilayer Composite Premade Bag (e.g.: PET/PE)
Bag Type
3 Side Seal Bag, Stand-up Bag
Upgradable Bag Type
Gusset Bag, Zipper Bag, Flat Bottom Pouch (Need additional purchase of functional device)
Size Range
80mm≤W≤300mm 100mm≤L≤430mm
Speed
0~15bags/min
Sealing Type
Straight grain, pitch is 1mm (Optional reticulate)
Sealing Width
10mm (5--20mm can be customized)
Voltage
220V, Single-phase, 50/60HZ, 1.2KW
Air Pressure
0.65Mpa
 Air Consumption
0.3m³/min (Standard machine, no additional function)
 Body Dimension
1770*600*1360mm
 Packing Dimension
1860*710*1650mm (Export non-fumigation wooden case)
Working Process:

1. Bag giving

2. Date coding(options)

3. Bag opening

4. Filling and vibrating

5. Straighten

6.To vacuum chamber

7. Forming and product output
