Automatic Horizontal Sauce Retort Pouch Filling Sealing Packaging Machine

Application:

Designed for Liquids and Semi-Liquids: This machine specializes in automatic packing for retort pouches, ideal for high-temperature sterilized products. It handles sauces, rice vinegar, juices, beverages, tomato paste, peanut butter, jams, ready-to-eat meals, soups, broths, and pet food, ensuring safe and long-lasting packaging. Perfect for the food industry’s shelf-stable needs.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. Versatile Sauce Packaging: Designed specifically for efficiently packaging various sauces, soups, and dips, catering to diverse liquid-based products.

2. Enhanced Seal Security: Features a double-sealing mechanism that ensures a secure, leak-proof closure and an improved visual appeal.

3. Adaptable Filling Capability: Equipped with an extra-large filling tube, capable of handling both sticky and non-sticky sauces, accommodating different consistencies with ease.

4. Premium Bag Presentation: Utilizes premade bags to elevate product presentation, providing a premium look and added market value.

Application:

Designed for Liquids and Semi-Liquids: This machine specializes in automatic packing for retort pouches, ideal for high-temperature sterilized products. It handles sauces, rice vinegar, juices, beverages, tomato paste, peanut butter, jams, ready-to-eat meals, soups, broths, and pet food, ensuring safe and long-lasting packaging. Perfect for the food industry’s shelf-stable needs.

Videos Introduction:

Specification:

Model	LDSP-160	LDSP-160Y	LDSP-210	LDSP-260
Bag Type	3-Side, 4-Side Sealing Bag, Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag, etc.
Bag Size	110-230mm(L); 80-160mm(W)	70-100mm(L); 110-230(W)	100-210mm(L); 110-320mm(W)	100-260mm(L); 110-320mm(W)
Filling range	10g-100g	10g-100g	10g-1kg	10g-3kg
Packing speed	20-45 bags/min	25-50 bags/min	20-50 bags/min	20-50 bags/min
Machine weight	800 kg	800 kg	900 kg	1000 kg
Total power	2 KW	2 KW	2 KW	2 KW
Workflow	1. Giving bag, 2. Pick up the bag(coding), 3. Open the bag up and down, 4. Filling, 5. Heating sealing, 6. Output of product
Dimensions	175012851360mm(LWH)		21401366 1360mm(LWH)	21401366 1360mm(LWH)
Collocation	Screw metering, screw elevator

Workflow:

1. Horizontal storage tank

2. Vertical bag feeder

3. Ribbon code print

4. Open bag

5. Filling

6. Hot sealing

7. Output
