Automatic Vertical Powder Pouch Packaging Machine With 280L Storage Tank

Application:

Automatic vertical powder pouch packaging machine with 280L storage tank is suitable for weighing packing powder material, such as milk powder, flour, protein powder, detergent powder, coffee powder, seasoning powder, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Optional:
Inquiry
Features:

1. Comes with a stop-leak valve (the packaging will not contain materials).

2. The bag making machine is equipped with rolling balls (to prevent the film from slipping).

3. Pin bag (the gusset can be closed to make a back-sealed bag), two bag types in one machine.

4. Dosing storage tank.
Application:

Automatic vertical powder pouch packaging machine with 280L storage tank is suitable for weighing packing powder material, such as milk powder, flour, protein powder, detergent powder, coffee powder, seasoning powder, etc.

It can adopt all type of 3/4 sided seal bag, gusset bag, pillow bag, back sealing bag, etc.
 powder pouch packing machine
Videos Introduction:
Specification:
Model LD-420 LD-520 LD-720 LD-900 LD-1050 LD-1200
Film Thickness 0.04-0.08mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Bag Length 80-300mm 80-350mm 100-500mm 100-600mm 100-800mm 100-1000mm
Bag Width 60-200mm 100-250mm 180-350mm 260-430mm 290-505mm 290-580mm
Film Roll Diameter Max.320mm Max.320mm Max.320mm 400mm 400mm 400mm
Pakaging Rate 5-60bag/min 5-60bag/min 5-55bag/min 5-20bag/min 5-20bag/min 5-20bag/min
Film Width Max.420mm Max.520mm 150-Max.720mm Max.900mm Max.900mm Max.1200mm
Measurement Range 150-1500ml 5-2000ml 4000ml 1-25L 1-25L 1.5L-45L
Optional:

LD series main frame

Screw metering machine

Screw infeed conveyor

Product conveyor

Storage tank
