Fully Auto Standup Pouch Powder Doypack Filling Packing Machine With Auger Weighting

Application:

Landpack powder premade bag packing machine is widely used in food factory, chemical factory, suitable for packing all kinds of powder product, such as, rice flour, coffee powder, sulfur powder, milk powder, seasoning powder, etc. According to customer needs,the machine can use stand up bag, gusset bag, zipper bag, pouch,three sides seal, four side seal etc. bag types.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1.Optional Six/Eight position Doy Packing Machine

2.Be equipped with automatic diagnostic & safety & alarm system, make it most to ensure personal safety and reducing material loss;

3.Can be equipped with remote diagnostic system, help customer to troubleshooting in minimum duration;

4.Can be equipped with self-lubrication system, prolong mechanism life, and reduce labor cost;

5.Can be equipped with pouch width adjustable mechanism, unit can be converted to different pouch just by one button in few seconds;

6.Unit made by highly strict manufacturing process, most components are provide by international top brand;

7.Comply with International Safety & hygienic Regulation, each unit shall pass safety, RoHs, physical properly and function test;

8.Attractive appearance, simple operation, reliable performance, low failure rate;

Application:

Landpack powder premade bag packing machine is widely used in food factory, chemical factory, suitable for packing all kinds of powder product, such as, rice flour, coffee powder, sulfur powder, milk powder, seasoning powder etc.

It can adopt all type of heat sealable performed side seal bags, block bottom, bags, zip-lock recloseable bags, stand-up pouch with or without spout, paper bags, flat pouch, stand-up pouch, zipper pouch, spout pouch, m gusset pouch, paper pouch, aluminium foil pouch, etc.

This Packing System is Just for Your Reference.We Will Offer You the Best Solution According to Your Product Mobility, Viscosity, Density, Volume, Dimensions, Etc.

Powder Packing Solution —— Servo Screw Auger Filler Is Specialized for Power Filling Such as Nutrients Power, Seasoning Powder, Flour, Medicinal Powder, Etc.

Liquid Packing Solution —— Piston Pump Filller Is Specialized for Liquid Filling Such as Water, Juice, Laundry Detergent, Ketchup, Etc.

Solid Packing Solution —— Combination Multi-head Weigher Is Specialized for Solid Filling Such as Candy, Nuts, Pasta, Dried Fruit, Vegetable, Etc.

Granule Pack Solution —— Volumetric Cup Fillier Is Specialized for Granule Filling Such as Chemial, Beans, Salt, Seasoning, Etc.

Samples:

Specification:

The Main Technical Parameters
Model	LD 8200D/ 8300D
Bag Size	Width:80-210/200-300mm, Length:100-300/100-350mm
Filling Volume	5-2500g (Depending on type of products)
Capacity	30-60bags/min (The speed depends on type of products and packaging material used)
Capacity	25-45bags/min (For zipper bag)
Package Accuracy	Error≤±1%
Total Power	2.5KW (220V/380V,3PH,50HZ)
Demension	171015051640 (LWH)
Weight	1480KGS
Compress Air Requirement	≥0.8m³/min supply by user
We can customize the suitable one for you according to your requiredment.
Just Tell us : Weight or Bag Size required.

Work Process
Safety Measures	1.no bag feeding, no filling and no sealing.
	2.no bag opening/open error, no filling and no sealing
	3.no filling, no sealing
Product Process	Station 1 Bag Feeding
	Station 2 Date Printing (option)and Open zipper bag
	Station 3 Open bag
	Station 4 Filling Materials
	Station 5,6,7 :Vibration,Air Removal,Nitrogen Filling,Close Zipper,Hole Punching,Heat Sealing
	Remark:No.5.6.7.Stations are based on customer requirements for adjusting.
	Station 8 Heat Sealing and Product Output
Stations are based on customer requirements for adjusting.

Optional:

1: LD series main frame

2: Screw metering machine

3: Screw infeed conveyor

4: Product conveyor
