High Efficiency Granule Rotary Type Zipper Pouch Packing Machine

Application:

High Efficiency Granule Rotary Type Zipper Pouch Packing Machine is suitable for small granule material, such as beans, chips, cookies, jerky, nuts, dry fruits, raisin, candy, cereal, chocolate, biscuit, peanut, capsule, seeds, chemicals, sugar, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

1. Automatically check bag open status, it will not fill and seal when bag is not opened fully. It avoids the wasting of bag and raw material and save cost.

2. Machine working speed can be adjusted continuously with frequency converter.

3. Machine will alarm when the air pressure is abnormal and stop working with overload protect and safety device.

4. Machine can work with dual-fill, filling with two types of material, such as solid and liquid.

5. Adopting advanced bearing, where no need to add oil and less pollution for product.

6. All the product and bag contact parts are made with stainless steel or the material according with the food hygienic requirements, guarantee hygiene and security of the food.

7. With premade bag, the pattern and sealing on the bag is perfect. The finished product looks advanced.
Application:

It is suitable for weighing grain, stick, slice, globose, irregular shape products such as candy, chocolate, jelly, pasta, melon seeds, roasted seeds, peanuts, pistachios, almonds, cashews, nuts, coffee bean, chips ,raisins, plum, cereals and other leisure foods, pet food, puffed food, vegetable, dehydrated vegetables ,fruits, sea food, frozen food, small hardware, etc.

Videos Introduction:
Specification:
Item High Efficiency Granule Rotary Type Zipper Pouch Packing Machine
Brand Landpack
Model LDSP-160 LDSP-160Y LDSP-210 LDSP-260
Bag Size 110-230mm*80-160mm(L*W) 70-100mm*110-230(L*W)     100-210mm/110-320mm(L*W) 100-260mm/110-320mm(L*W)
Filling Range 10-100 g 10-100 g 10 g - 1 kg 10g-3kg
Bag Type 3-side sealing bag, 4-side sealing bag, stand-up bag, handbag, zipper bag, compound bag, etc.
Speed 20-45bags/min 25-50bags/min 20-50bags/min 20-50bags/min
Total Power 2.0 KW
Machine Weight 800 KG 900 KG 1000KG
Dimension 1750*1285*1360 mm (L*W*H) 2140*1366*1360 mm (L*W*H)
Work Flow 1. Giving bag 2. Pick up the bag(coding) 3. Open the bag up and down 4. Filling 5. Heating sealing 6. Output of product
Collocation Screw Metering, Screw Elevator
Working Process:

1. Bag Giving

2. Pick Up the Bag(Coding)

3. Open the Bag Up and Down

4. Filling

5. Heating Sealing

6. Output of Product
