Hot Selling Mini Doypack Liquid Pouch Packing Machine For Zipper Pouch Spout Pouch

Application:

Mini doypack machine is suitable for all kinds of the premade bags, such as stand up pouch, zipper bag, box pouch, kraft paper bags, corner spout bags and so on; By connecting with different weighing equipments, the packing system can handle various products, such as powder, snacks, dried vegetable or fruit, puffed food, liquid sauce, beverage, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. Easy to operate;

2. Automatic checking: no pouch or pouch open error, no fill, no seal, avoid wasting;

3. Safety device: Machine stop at abnormal air pressure, heater disconnection alarm;

4. Adjustable bag width;

5. Glass safety door: It will stop working when you open the door, ensure the safety of operators;

6. Low loss of packing materials, high quality of the sealing part, to improved the product specification;

7. Different feeding hoppers: for solid, liquid, thick liquid ,powder and so on;

8. Bag materials: Suits in extensive range;

Application:

Mini doypack machine is suitable for all kinds of the premade bags, such as stand up pouch, zipper bag, box pouch, kraft paper bags, corner spout bags and so on; By connecting with different weighing equipments, the packing system can handle various products, such as powder, snacks, dried vegetable or fruit, puffed food, liquid sauce, beverage, etc.

Samples:

Specification:

Type	Hot Selling Mini Doypack Liquid Pouch Packing Machine For Zipper Pouch Spout Pouch
	LDB-200	LDB-300	LDB-430
Bag Material	Multi-layer Composite Premade Bag（e.g.: PET/PE）
Premade bag type	all kinds of the premade bags, such as stand up pouch, zipper bag, box pouch, kraft paper bags, corner spout bags and so on
Upgraded Bag Type	（Need additional purchase of functional device）	Gusset Bag, Zipper Bag, box bag (Need additional purchase of functional device
Bag size	70mm≤W≤150mm	80mm≤W≤300mm	80mm≤W≤300mm
	70mm≤L≤150mm	100mm≤L≤300mm	100mm≤L≤430mm
Speed	0~60bags/min	0~15bags/min
Sealing Type	Straight grain, pitch is 1mm (Optional reticulate)
Sealing Width	10mm（5--20mm) can be customized
Voltage	220V, Single-phase,50/60HZ, 1.2KW
Air Pressure	0.65Mpa
Air Consumption	Standard machine, no additional function
Body Dimension	17706001230mm	17706001360mm
Packing Dimension	18607101550mm	18607101650mm
	Export non-fumigation wooden case

Optional:

Machine machine can equipment with different metering system like weigher, liquid pump, auger filler, bucket chain for different kinds of product filling and packing in premade bag.
