Automatic Nut Bolt Nail Screw Counting And Packing Machine Automatic Screw Packing Machine

Application:

The fastener packaging machine is suitable for packaging hardware parts and ensuring accurate quantity, such as nuts, screws, O-rings, and so on.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;

Features:

1. Integrated Weight Checker for Each Bowl – Ensures precise verification of fastener quantities, guaranteeing 100% accuracy in every pouch.

2. Automated Counting for Up to 18 Types of Fastener – Significantly reduces labor costs, eliminating the need for 18 to 20 workers.

3. Flexible Operation with Support Platform – Allows workers to manually place large items or new fastener for seamless integration into the packaging process.

4. Smart Date Printer – Directly prints product information and company logos onto the packaging for a professional finish.

5. Automatic Weight Checker at the End of the Line – Identifies and removes incorrect pouches, ensuring only compliant packages proceed.

Application:

The fastener packaging machine is suitable for packaging hardware parts and ensuring accurate quantity, such as nuts, screws, O-rings, and so on.

Videos Introduction:

Specification:

Model	LD-XC90D
Film Width	200-620mm
Bag Width	90-290mm
Bag Length	90-300mm
Packing Speed	5-40 Bags/Min
Box Width	90-150mm
Box Length	90-245mm
Packing Speed	12-18 Boxes/Min
Voltage	3Kw 220/380V 50/60Hz
Economic Benefit
Case 1: Economic Benefits Brought By The Screw Packaging System
Take the "landpack" screw packaging system used by a certain manufacturer as an example. The factory originally used manual weighing and packaging, but after it was put into the screw packaging system, there were the following obvious changes.
Comparison Item	Artificial Weighing + Packing	After Using The Packaging System
Average Weight Deviation Of A Single Bag	≤5g	≤2g (Saved 3 grams)
Need Labor	10 people	3 people（Saved 7 Labor）
Hygiene Situation	⭐⭐	⭐⭐⭐⭐⭐
Energy Consumption	⭐⭐	⭐⭐⭐
Product Waste	⭐⭐⭐⭐⭐	⭐⭐
Production Management	Not easy to manage	Digital management
Production Layout	Labor-intensive and complex production environment.	Mechanical automation, simple and beautiful production environment.

Working Process:

1.Each bowls count and feed the fastener.

2.Feeding the large fasteners by the workers

3. Printing the information and logo on the pouch.

4. Forming, sealing pouch and output.

5. Double Checking by the weight checker.
