Multifunction Fastener Hardware Metal Washer Bag Weighing Packing And Boxing Machine Line

Application:

High speed of 20 to 30 double opening cartonning packing system. Applications and is used in boxing and packaging of fasteners, hardware, auto parts and other industries. such as screw, nail, bolt, pin, button etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Benefit:
Inquiry
Features:

1.Heavy bag packing and boxing.

2. Save labor cost and improve efficiency.

3. Suitable for PE material film, beautiful sealing and high accurate weighing.
Application:

High speed of 20 to 30 double opening cartonning packing system. Applications and is used in boxing and packaging of fasteners, hardware, auto parts and other industries. such as screw, nail, bolt, pin, button etc.
Videos Introduction:
Specification:
Model
LD-420
LD-520
LD-720
LD-900
Film width
Max.420mm
Max.520mm
Max.720mm
Max.900mm
Bag length
80-300mm
80-350mm
100-500mm
100-600mm
Bag width
60-200mm
100-250mm
180-350mm
260-430mm
Film roll diameter
Max.320mm
Max.320mm
Max.320mm
400mm
Packaging rate
5-60 bag/min
5-60 bag/min
5-55 bag/min
5-20 bag/min
Range of measurement
150-1500ml
2000ml
4000ml
1-25L
Film thickness
0.04-0.08mm
0.04-0.12mm
0.04-0.12mm
0.04-0.12mm
Power
220V 50/60Hz 2kw
220V 50/60Hz 3kw
220V 50/60Hz 3kw
220V 50/60Hz 4.5kw
Machine size(LxWxH)
1217x1015x1343mm
1488x1080x1490mm
1780x1350x2050mm
2305x1685x2725mm
Machine quality
About 650kg
About 680kg
About 750kg


Benefit:
Economic Benefit
Case 1: Economic Benefits Brought By The Screw Packaging System
Take the "landpack" screw packaging system used by a certain manufacturer as an example. The factory originally used manual weighing and packaging, but after it was put into the screw packaging system, there were the following obvious changes.
Comparison Item Artificial Weighing + Packing After Using The Packaging System
Average Weight Deviation Of A Single Bag ≤5g ≤2g (Saved 3 grams)
Need Labor 10 people 3 people(Saved 7 Labor)
Hygiene Situation ⭐⭐ ⭐⭐⭐⭐⭐
Energy Consumption ⭐⭐ ⭐⭐⭐
Product Waste ⭐⭐⭐⭐⭐ ⭐⭐
Production Management Not easy to manage Digital management
Production Layout Labor-intensive and complex production environment. Mechanical automation, simple and beautiful production environment.
