Automatic Panasonic Servo Motor Fluidic Powder Canning Filling Machine Lines

Application:

This machine is suitable for the packing of foodstuff, chemical products, medicinal. For example: milk powder, soy milk powder, oatmeal, sesame paste, sugar, flavoring, seasoning and all kinds of medicine taken with water.

Details:

Type:LD-PAF01
Packing speed: 10-40 cans/min
Power: 4.5KW
Control system: PLC
Weight: 500kg
Packing type: CANS, Bottles, Barrel, Other
Packing Material: Metal,Pleastic

Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Optional:
Inquiry
Features:

1.Adopt servo system to control screw feeding, photoelectric sensor technology.

2.Transparent silo design, easy to observe the material level.

3.Stainless steel structure, stable structure, removable and easy to clean and maintain.

4.Suitable for packaging containers of bottles and cans, size and type, wide adjustable range.

5.The Auger can be replaced, the accuracy and efficiency can be taken into account.

6.Intelligent induction positioning and blanking without filling without tank.

7.Weighing feedback system, the error is corrected in time, and the accuracy is more stable.

8.Fault self-diagnosis alarm function, operation problems are clear.

9.Can be used with a variety of automatic packaging equipment, convenient connection.
Application:

Automatic milk powder flour filling seaming labeling lines is mainly suitable for packing cans/bottles of all kinds of powder materials. Such as milk powder, coffee powder, protein powder, grains powder, nutritional powder, tea powder, chilli powder, and so on.

Videos Introduction:
Specification:
Model LD-PAF01
Filling Speed 10-40 cans/min
Filling accuracy ±1%
Bottle Diameter Φ30mm-Φ140mm (customizable)
Bottle Height 50mm-200mm (customizable)
Control system PLC
Packing Material Jars/ bottles/ cans
Power supply 220V, 50Hz, 2.5 KW
Airconsumption 0.5-0.8 m³/min
Equipment material 304
Optional:

1.Bottles/ cans unscrambler

2.Capping Machine

3.Labeling Machine

4.Shrink Wrap Machine
