Multi Line Side Sealing Bag Hand Sanitizer Sachet Packing Machine

Application:

Suitable for many kinds of liquid products, such as disposable hand sanitizer,alcohol,disinfectant liquid, shampoo, ketchup, honey, sauce, oil, paste, ice candy, etc.

Details:

Model:LDGH500LS

Track number:1-4Track

Capacity:20-30 cycle/min

Sachet size:L:50-170mm;W:40-230mm

Sealing type:Irregular shape bag

Film width&thickness:Max.500mm;0.07-0.10m

Filling method:1.Piston pump;2.Peristaltic pump

Powder supply:220V/380V 50HZ,/5.5KW

Air consumption:0.8MPA 0.8m3/min

Dimension&weight:2600*1350*2350mm,800kg

E-mail: [email protected]

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Samples:

Specification:

Package Material:

Features:

Multi lanes machine can produce multi lanes bags at same time.

Machine main function: automatic split film at right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.

Other function: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step etc.

Stainless steel contact part and the machine outer shell, high feature for liquid running environment.

High precision photocell sensor for auto tracking the eye mark printing on the film roll, so cut each bag at precisely position.

PLC controller, high function and control the whole machine’s work steps.

Application:

Suitable for many kinds of liquid products, such as disposable hand sanitizer,alcohol,disinfectant liquid, shampoo, ketchup, honey, sauce, oil, paste, ice candy, etc.

Samples:

Specification:

Model	LD-480Y	LD-720Y	LD-960Y
Track Number	4~6 Track	4~10 Track	4~12 Track
Filling Method	1.Piston pump; 2.Peristaltic Pump	1.Piston pump; 2.Peristaltic Pump	1.Piston pump; 2.Peristaltic Pump
Capacity	Max.40 cycle/min	Max.40 cycle/min	Max.40 cycle/min
Sachet Size	L:45--120mm; W:35-60mm	L:45--120mm; W:35-90mm	L:45--120mm; W:35-120mm
Film Width & Thickness	Max.480mm;0.07-0.1mm	Max.720mm;0.07-0.1mm	Max.960mm;0.07-0.1mm
Sealing Type	4 sides sealing	4 sides sealing	4 sides sealing
Cutting Type	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power	0.8 mpa 0.8m³/min; 2.8kw	0.8 mpa 0.8m³/min; 4.1kw	0.8 mpa 0.8m³/min; 5.5kw
DIM & WT	95014701750mm; 300kg	115316541750mm; 400kg	141516862130mm; 500kg

Package Material:

BOPP/CPP/VMCPP.

BOPP/PE

PET/VMPET

PE,PET/PE,etc
