High Speed Popcorn Packing Machine High Yield Popcorn Packing Line System

Application:

This Vertical Form Fill Sealing (VFFS) Packing Line System is suitable for various granular products, such as: 1. Food Industry: peanuts, popcorn, jelly, data, garlic, beans, grains, soybeans, pistachios, walnuts, rice, corn, sunflower seeds, melon seeds, coffee beans, potato chips, banana chips, plantain chips, chocolate ball, shrimp, sweet candy, sugar, tea, herbs, Chinese medicine, puffed food, dry food, frozen food, frozen vegetables, frozen pea, frozen fish ball, frozen pie, and other granule products; 2. Pet Food Industry: dog food, bird food, cat food, fish food, poultry food and etc; 3. Hardware Industry: plastic pipe elbows, nails, bolts and nuts, buckles, wire connectors, screws and other construction products.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Workflow:
Inquiry
Features:

1.This packaging solution is suitable for large production packing, adopt new design, beautiful appearance, the structure is more reasonable, more advanced technology.

2. Customized language screen display. PLC control, servo motor, very easy to operate. Do not need to stop machine to adjust any parameters.

3. Fully automatic bag forming, dosing Filling, sealing, coding, conveying, counting can be finished in one operation, most labor-saving equipment.

4. High quality stainless steel, suitable for GMP, good for food packaging with high standard.

5. Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.

6. Pocket diversification, can provide customers with pillow bags, angled bags, hanging-hole bags, vertical bags, punched bags, etc.

7. A variety of automatic alarming protective function, maximum limit to reduce wear and tear.

8. Double sever motors, drawing film position accurately, and the speed is faster.

9. Temperature independent control system, precision get to ±1°C.
Application:

This Vertical Form Fill Sealing (VFFS) Packing Line System is suitable for various granular products,

1. Food Industry: peanuts, popcorn, jelly, data, garlic, beans, grains, soybeans, pistachios, walnuts, rice, corn, sunflower seeds, melon seeds, coffee beans, potato chips, banana chips, plantain chips, chocolate ball, shrimp, sweet candy, sugar, tea, herbs, Chinese medicine, puffed food, dry food, frozen food, frozen vegetables, frozen pea, frozen fish ball, frozen pie, and other granule products;

2. Pet Food Industry: dog food, bird food, cat food, fish food, poultry food and etc;

3. Hardware Industry: plastic pipe elbows, nails, bolts and nuts, buckles, wire connectors, screws and other construction products.
Videos Introduction:
Specification:
Model LD-420A per machine LD-520A per machine LD-720A per machine
Film Width Max.420mm Max.520mm Max.720mm
Bag Length 80-300mm 80-350mm 100-500mm
Bag Width 60-200mm 100-250mm 180-350mm
Roll Diameter Max.320mm Max.320mm Max.320mm
Film Thickness 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Packing Speed 5-60bag/min 5-60bag/min 5-55bag/min
Power 220V 50/60Hz 2KW 220V 50/60Hz 3KW 220V 50/60Hz 3KW
Machine Size (L)1217*(W)1015*(H)1343mm (L)1488*(W)1080*(H)1490mm (L)1780*(W)1350*(H)2050mm
Machine Weight About 650kg About 680kg About 750kg
Option Device Two synchronous belt device, air filling device, angle fold device,automatic rectifying device, hole-punching device, link bag device.
Workflow:

Feeding, Measuring, Bagging, Date printing, Charging(Exhausting) realising fully automation.
