High Speed Semi Auto Granule Vertical Packing Machine With Measuring Cups

Application:

Suitable for packing all kinds of grain material, sheet material, strip material, and abnormity material such as candy, melon seeds, chips, peanuts, nutlets, preserved fruit, jelly, biscuit, confect, camphor ball, currant, almond, chocolate, filbert, corn.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

The whole machine adopts 3 servo control system, the machine runs smoothly, the action is accurate, the performance is stable, and the packaging efficiency is high

The whole machine adopts 3mm & 5mm thick stainless steel sheet metal processing and assembly, running smoothly; and the core components are specially optimized design, and the packaging speed is fast;

The equipment adopts servo-driven film pulling and unwinding to ensure precise film pulling and neat and beautiful packaging bags;

It can be matched with combination weigher, screw, measuring cup, drag bucket, liquid pump to achieve accurate and efficient measurement; (the above functions have been standard in the packaging machine program)

The equipment accessories adopt domestic/international famous brand electrical components, and have been tested by many years of market practice to ensure more stable and durable performance;

The design of the whole machine complies with GMP standards and has passed CE certification.
Application:

Suitable for packing all kinds of grain material, sheet material, strip material, and abnormity material such as candy, melon seeds, chips, peanuts, nutlets, preserved fruit, jelly, biscuit, confect, camphor ball, currant, almond, chocolate, filbert, corn.

It can adopt all type of 3/4 sided seal bag, pillow bag, back sealing bag, etc.
 vertical form fill and seal machine

Videos Introduction:
Specification:
Model LD-320SF
Capacity 20-100 bags/min
Bag size L: 50-170mm, W: 50-150mm
Film width 120mm-320mm
Film thickness 0.05-0.12mm
Control system PLC+Servo Motor+Color Touch Screen; PLC+Servo+Touch screen
Power supply 1N+PE/50HZ/AC220V  4KW
Airconsumption 0.6-0.8Mpa, 0.3-0.5㎥/h
Dimension L1350*W900*H1400mm
Equipment Material Main body 3mm thickness 304 stainless steel frame
Weight 350kg
Description of Main Packaging Process Pulling film-coding-bag making-measurement-filling (inflating)-sealing (punching)-cutting-packaging finished product output.

Working Process:

Pulling film

Coding

Bag making

Measurement

Filling (inflating)

Sealing (punching)

Cutting

Packaging finished product output
