High Speed Automatic Multilane Liquid Sachet Counting Into Bag Packaging Line

Application:

Automatic multilane liquid sauce sachet counting into pouch packaging line is suitable for the packaging of various liquid products, such as ketchup, paste, honey, chili sauce, bean paste, instant noodle sauce, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. Enhanced Production Efficiency: The inclusion of two liquid multi-channel packaging machines significantly boosts your production and packaging capabilities.

2. Precise Counting and Collection: At the conveyor outlet, a counting sensor and collection device work in tandem. They accurately collect the desired number of small bags and seamlessly discharge them onto the chain conveyor.

3. High-Sensitivity Imported Counting Sensor: The counting sensor, sourced internationally, exhibits exceptional sensitivity. This ensures precise counting, meeting your target quantity consistently.

4. Servo Motor-Driven Inclined Conveyor: The inclined conveyor is powered by a servo motor. It remains stationary unless materials are present, optimizing efficiency and preventing unnecessary movement.

Application:

Automatic multilane liquid sauce sachet counting into pouch packaging line is suitable for the packaging of various liquid products, such as ketchup, paste, honey, chili sauce, bean paste, instant noodle sauce, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.

It can adopt all type of 3/4 sided seal bag, pillow bag, sachet, back sealing bag, etc.

Videos Introduction:

Specification:

Multi-Channel Packaging Machines Parameter
Model	LD-480Y	LD-720Y	LD-960Y
Track Number	4-6 Track	4-10 Track	4-12 Track
Filling Method	1.Piston pump; 2.Peristaltic Pump
Capacity	Max.40 cycle/min
Sachet Size	L: 45-120mm; W: 35-60mm	L: 45-120mm; W: 35-90mm	L: 45-120mm; W: 35-120mm
Film Width & Thickness	Max.480mm;0.07-0.1mm	Max.720mm;0.07-0.1mm	Max.960mm;0.07-0.1mm
Sealing Type	3/4 sides sealing	3/4 sides sealing	3/4 sides sealing
Cutting Type	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power	0.8 mpa, 0.8m³/min, 2.8kw	0.8 mpa, 0.8m³/min, 4.1kw	0.8 mpa, 0.8m³/min, 5.5kw
DIM & WT	95014701750mm; 300kg	115316541750mm; 400kg	141516862130mm; 500kg
Vertical Form Fill Seal Machine Parameter
Model	LD-420	LD-520	LD-720
Film Thickness	0.04-0.08mm	0.04-0.12mm	0.04-0.12mm
Bag Length	80-300mm	80-350mm	100-500mm
Bag Width	60-200mm	100-250mm	180-350mm
Film Roll Diameter	Max.320mm	Max.320mm	Max.320mm
Pakaging Rate	5-60 bags/min	5-60 bags/min	5-55 bags/min
Film Width	Max.420mm	Max.520mm	150-Max.720mm
Measurement Range	150-1500ml	5-2000ml	4000ml

Packing type:

1. Weighing

2. Measuring

3. Bag making

4. Filling

5. Sealing

6. Cutting

7. Counting

8. Product conveyance
