Multi Track Lane Shampoo Sachet Bag Packing Packaging System With Cartoning Machine

Application:

It can be used to pack food, chemical, cosmetics etc.Such as shampoo, edible oil, cooking oil, facial cream, skin cream, hair cream, fruit juice, ketchup, sauce, tomato paste, juice paste, butter etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. It can automatically finish measuring, bag making, sealing, cutting, counting, finishing product conveyor, cartoning and other functions;

2. The heat-generating parts and moving parts are hidden in the protective cover;

3. The contact part of the box and material is made of 304 stainless steel, which meets the requirements of medicines and food production;

4. The equipment is equipped with casters for easy handling and movement.

5. Automatic alarm protection, saving materials, and no wasting film.

Application:

It can be used to pack food, chemical, cosmetics etc.Such as shampoo, edible oil, cooking oil, facial cream, skin cream, hair cream, fruit juice, ketchup, sauce, tomato paste, juice paste, butter etc.

Videos Introduction:

Specification:

Multi Lane Packing Machine Parameters
Model	LD-480Y	LD-720Y	LD-960Y
Track Number	4-6 Track	4-10 Track	4-12 Track
Filling Method	1.Piston pump; 2.Peristaltic Pump
Capacity	Max.40 cycle/min
Sachet Size	L: 45-120mm; W: 35-60mm	L: 45-120mm; W: 35-90mm	L: 45-120mm; W: 35-120mm
Film Width & Thickness	Max.480mm;0.07-0.1mm	Max.720mm;0.07-0.1mm	Max.960mm;0.07-0.1mm
Sealing Type	3/4 sides sealing	3/4 sides sealing	3/4 sides sealing
Cutting Type	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power	0.8 mpa, 0.8m³/min, 2.8kw	0.8 mpa, 0.8m³/min, 4.1kw	0.8 mpa, 0.8m³/min, 5.5kw
DIM & WT	95014701750mm; 300kg	115316541750mm; 400kg	141516862130mm; 500kg

Fully Automatic Cartoning Machine Parameters
Model	LD-200ZH
Paper type	250-400g/㎡(Boxes need come with pre-fold over)
Capacity	30-60 boxes/min
Box type	Gusseted tongue type; Glue spray type
Count way	Fixed number type; Numerable type; Manipulator counting
Boxing way	Ordely type; Unorderly type
Air & Power	0.5-0.8Mpa 0.3m³/min;220V 50/60HZ 2.0KW
Work flow	Box open - Bag packing - Check weigher - Counting - Boxing- Fold ears - Fold page - Gusseted tongue/Glue spray - Finish

Packing type:

1.Sealing type:4 sides sealing;

2.Cutting type:Straight cutting; Zig zag cutting; Round cutting; Irregular
