Multifunction Ketchup/ Sauce Sided Seal Packing Machine Liquid Sachet Packing Machine

Application:

Suitable for side sealing of conventional liquids such as sauces, ketchup, chili sauce, tomato sauce, shampoo, laundry detergent, honey, vitamin water, juice drinks, oil, water, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Combined Parts:
Inquiry
Features:

1.Computer PLC control and automatic alarming function.

2.Multilingual screen display, easy operation.

3.High sensitivity photoelectric eye color tracing,more accuracy.

4.Bag type can be customised to 3 or 4 sides sealing bag, pillow bag, long stick bag, link bag, etc.

4.Famous brand components, ensure the quality and durability of machine.

5.Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.

6.Ribbon code printer, link-bag device is option.

7.Multipurpose packaging, suitable for various packaging of different product.
Application:

Suitable for side sealing of conventional liquids such as sauces, ketchup, chili sauce, tomato sauce, shampoo, laundry detergent, honey, vitamin water, juice drinks, oil, water, etc.
Videos Introduction:
Specification:
Model LD-320L LD-380L
Film width 120-320mm 180-380mm
Bag length 50-200mm 60-280mm
Bag width 50-150mm 60-180mm
Diameter of film roll Max.300mm Max.320mm
Packing speed 35-70bag/min
Measuring range 50-500ml 50-750ml
Film thickness 0.04-0.07mm
Power 220V 50/60Hz 2.2KW 220V 50/60Hz 2.5KW
Machine size(L*W*H) 970*680*1950mm 1100*800*2150mm
Machine weight About 300kg About 450kg
Combined Parts:

1.LD series main frame

2.Screw metering machine

3.Screw infeed conveyor

4.Product conveyor
