Automatic Multi Lane Stick Pack Powder Fine Granule Packaging Boxing Production Line

Packaging Line Composition:

This Automatic Stick Pack Powder Fine Granule Packaging Boxing Production Line is suitable for the automatic packaging of particles with good fluidity in food, health care, and pharmaceutical industries such as instant coffee powder, fruit enzyme powder, white sugar, granule, Chinese medicine granule, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. It can automatically finish measuring, bag making, sealing, cutting, counting, finishing product conveyor, cartoning and other functions;

2. The heat-generating parts and moving parts are hidden in the protective cover;

3. The contact part of the box and material is made of 304 stainless steel, which meets the requirements of medicines and food production;

4. The equipment is equipped with casters for easy handling and movement.

5. Automatic alarm protection, saving materials, and no wasting film.

Application:

This Automatic Stick Pack Powder Fine Granule Packaging Boxing Production Line is suitable for the automatic packaging of particles with good fluidity in food, health care, and pharmaceutical industries such as instant coffee powder, fruit enzyme powder, white sugar, granule, Chinese medicine granule, etc.

Videos Introduction:

Specification:

MULTI-LANE STICK PACK POWDER PACKAGING MACHINE
Model	LD280BK
Lane number	2-6 Lanes
Filling Method	1. Volumetric cup; 2. Weigher;
Capacity	Max.50 cycles/min
Sachet size	L: 50-180mm; W: 17-65mm
Film width & Thickness	Max.280mm, 0.07-0.10mm
Sealing type	Back sealing/ Stick bag
Cutting type	1.Straight cutting; 2.Zig zag cutting; 3.Round cutting; 4.Die-cut
Air & Power	0.8Mpa, 0.8m³/min, 3.5kw
Dimension & weight	13859182005mm;350kg

BOXING MACHINE
Model	LD200ZH
Paper type	250-400 g/²(Boxes need come with pre-fold over)
Capacity	30-60 boxes/min
Box type	Gusseted tongue type; Glue spray type
Count way	Fixed number type; Numerable type; Manipulator counting
Boxing way	Orderly type; Unorderly type
Air & Power	0.5-0.8Mpa, 0.3m³/min, 220V, 50/60HZ, 2.0KW
Workflow	Box open - Bag packing - Check weigher - Counting - Boxing- Fold ears - Fold page - Gusseted tongue/Glue spray - Finish
