Automatic Multi Track Protein Powder Stick Packing Packaging Machine

Application:

It is suitable to pack powder materials in the fields of pharmacy industry, food industry and daily industry. Such as protein powder, milk powder, drug powder, bone-stronger powder, lotus powder and much more.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

1. Full material is 304 stainless steel.

2. Heavy-duty design suits for high-speed operation.

3. No waste of film design, no reserved film edge required.

4. Motorized Roller type film dividing device.

5. PLC & Touch screen HMI control.

6. Guided servo motorized film pulling device integrated with horizontal seal.

7. Individual servo auger dosing for each lane and automatic dosing range adjustment by PLC.

8. Intelligent PID temperature controller.
Application:

By configuring with different accessories, suitable for measuring normal or even free-flowing powders, such as milk powder, rice flour, protein powder, powdery drugs, powder additives, glucose, dyeing Ingredients, flavors, spices, etc.


Videos Introduction:
Specification:
 Model  LD-280BF  LD-560BF
 Lane number  4-6 Line  8-12 Line
 Filling Method  Auger filling by servo motor
 Capacity  Max.35 cycle/ min
 Sachat Size  L:50-180mm; W:17-30mm  L:50-180mm; W:17-30mm
 Film weidth & Thickness  Max.280mm, 0.07-0.10mm  Max.560mm, 0.07-0.10mm
 Sealing type  Back sealing/Stick bag  Back sealing/Stick bag
 Cutting type  1.Straight cutting;2.Zig zag cutting;3.Round cutting;4.Irregular
 Air & Powder  0.8Mpa 0.8m3/min; 3.5kw   0.8Mpa 0.8m3/min; 5.5kw
 Dimension & weight  1385*918*2005mm;350kg  1685*1300*2005mm;550kg
Working Process:

1. Vacuum feeder is more hygienic conveying of materials.

2. Air sharft roll film device.

3. Date coding.

4. Screw metering device with anti-leaking device.

5. Pulling film is under servo motor driven.

6. Pull packing film and sealing.

7. Feed powder into sachet.

8. Cutting and output the finished product.
