Custom OEM Milk Powder Pouch Packing Machine | Protein Powder Bag Packing Machine With Mixing Function

Application:

This machine is suitable for many kinds of powder such as: Milk powder, protein powder, flour, rice powder, protein powder, Seasoning powder, chemical powder, medicine powder, coffee powder, soy flour Etc.Full automatic pack machine, can fill weighing seal cut, fast speed and accuracy.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1）Imported PLC full computer control system, color touch screen, easy to operate, intuitive and efficient.

2）Impoted servo film transport system, imported color code sensor, accurate positioning, excellent overall performance and beautiful packaging.

3）A variety of automatic alarm protection functions to minimize losser.

4）Flat cutting, pattern cutting, linking cutting can be realized by changing the tools;easy operation with smooth bags.

5）Bag-making equipment can be changed according to specific requirement of customers and products.

6）Optional English or other languages screen display, easy and simple operation. Both packaging speed and bag length can be set with one click.

7）All machines have CE certification and ROSH certificate.

Application:

This machine is suitable for many kinds of powder such as: Milk powder, protein powder, flour, rice powder, protein powder, Seasoning powder, chemical powder, medicine powder, coffee powder, soy flour Etc.Full automatic pack machine, can fill weighing seal cut, fast speed and accuracy.

This machine can make back-seal packing. It can be upgraded to add the bag with hanging holes, bag with easy tear, gusseted bag and quad sealed bag effect according to the needs.

Videos:

Specification:

Model	LD--320D	LD-420D	LD-520D	LD-620D	LD-720D
Film Width	Max.320mm	Max.420mm	Max.520mm	Max.620mm	Max.720mm
Filling range	150~800ml	150~1500ml	150~2000ml	150~4000ml	150~400ml
Bag size	L:80~240mm W:50~150mm	L:80~300mm W:60~200mm	L:80~350mm W:80~250mm	L:150~350mm W:200~350mm	L:100~450mm W:100~350mm
Packing speed	5~70bags/min	5~60bags/min	10~50bags/min	5~50bags/min	10~40bags/min
Optional device	Angle of plug-in device, Linking bags device, Gas-filling device, Punching device

Workflow:

This machine is easy to operate: Just set the parameters on the screen, and then you can start the machine. Put the product in the hopper, the machine will automatically pull the film, the bag is formed, sealed, and finally the bag is cut.
