High Speed Multi Lane Fine Granule Stick Packing Filling Sealing Machine

Application:

High speed multi lane fine granule stick packing filling sealing machine suitable for many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, seasoning, fine granule, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

E-mail: [email protected]

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Videos Introduction:

Specification:

Cutting type:

Features:

Multi lanes machine can produce multi lanes bags at same time.

Machine main function: automatic split film at right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.

Other function: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step etc.

Stainless steel contact part and the machine outer shell, high feature for liquid running environment.

High precision photocell sensor for auto tracking the eye mark printing on the film roll, so cut each bag at precisely position.

PLC controller, high function and control the whole machine’s work steps.

Application:

High speed multi lane fine granule stick packing filling sealing machine suitable for many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, seasoning, fine granule, etc.

It can adopt all type of 3/4 sided seal bag, stick bag, back sealing bag, etc.

multi lane stick pack machine

Videos Introduction:

Specification:

Model	LD-280BF	LD-560BF
Lane number	4-6 Line	8-12 Line
Filling Method	1.Volumetric cup; 2. Weigher
Capacity	Max.35 cycle/ min
Sachat Size	L:50-180mm; W:17-30mm	L:50-180mm; W:17-30mm
Film weidth & Thickness	Max.280mm, 0.07-0.10mm	Max.560mm, 0.07-0.10mm
Sealing type	Back sealing/Stick bag	Back sealing/Stick bag
Cutting type	1. Straight cutting; 2. Zig zag cutting; 3. Round cutting; 4. Irregular
Air & Powder	0.8Mpa, 0.8m3/min; 3.5kw	0.8Mpa, 0.8m3/min; 5.5kw
Dimension & weight	13859182005mm; 350kg	168513002005mm; 550kg

Cutting type:

Straight cutting;

Zig zag cutting;

Round cutting;

Irregular
