Automatic Multilane Liquid Packing Machine Stick Bag Packing Into Pouch System

Packaging Line Composition:

This packaging system is consist of two LD-480YL Multi-lane side sealing ice lollies liquid packaging machines, a Sorting bag equipment, a LD-350 Flow packaging machine, a Check weigher, and a Metal detector. It can realize long four-sided sealing bag packaging into a pillow bag.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1. It can automatically finish measuring, bag making, sealing, cutting, counting, finishing product conveyor, secondary bagging, and other functional requirements can be customized;

2. The heat-generating parts and moving parts are hidden in the protective cover;

3. The contact part of the box and material is made of 304 stainless steel, which meets the requirements of medicines and food production;

4. The equipment is equipped with casters for easy handling and movement.

5. Automatic alarm protection, saving materials, and no wasting film.

Application:

This Automatic Multilane Liquid Packing Machine Stick Bag Packing Into Pouch System is suitable for the packaging of various liquid products, such as ketchup, paste, honey, chili sauce, bean paste, ice lollies, cream, milk, butter,jelly, etc.

Videos Introduction:

Specification:

Multi Lane Stick Packing Machine Parameters
Model	LD-480Y	LD-720Y	LD-960Y
Track Number	4-6 Track	4-10 Track	4-12 Track
Filling Method	1.Piston pump; 2.Peristaltic Pump
Capacity	Max.40 cycle/min
Sachet Size	L: 45-120mm; W: 35-60mm	L: 45-120mm; W: 35-90mm	L: 45-120mm; W: 35-120mm
Film Width & Thickness	Max.480mm;0.07-0.1mm	Max.720mm;0.07-0.1mm	Max.960mm;0.07-0.1mm
Sealing Type	3/4 sides sealing	3/4 sides sealing	3/4 sides sealing
Cutting Type	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power	0.8 mpa, 0.8m³/min, 2.8kw	0.8 mpa, 0.8m³/min, 4.1kw	0.8 mpa, 0.8m³/min, 5.5kw
DIM & WT	95014701750mm; 300kg	115316541750mm; 400kg	141516862130mm; 500kg

Flow Pack Machine Parameters
Model	LP-350	LP-400	LP-450	LP-600	LP-700
Film Width	Max.350mm	Max.400mm	Max.450mm	Max.600mm	Max.700mm
Bag Length	65-330mm	150-400mm	150-450mm	160-500mm	180-600mm
Bag Width	50-160mm	50-180mm	50-180mm	100-280mm	100-330mm
Products High	Max.60mm	Max.65mm	Max.75mm	Max.110mm	Max.110mm
Film Roll Diameter	Max.320mm	Max.320mm	Max.320mm	Max.320mm	Max.320mm
Packing Speed	40-180bag/min	30-150bag/min	30-150bag/min	20-150bag/min	20-130bag/min
Power	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz
Power	2.6KW	2.8KW	2.8KW	2.8KW	2.8KW
Machine Size	40307701420	40307701420	40308201420	40309701500	403010701500
(LWH)mm	40307701420	40307701420	40308201420	40309701500	403010701500
Machine Weight	About 580kg	About 600kg	About 650kg	About 680kg	About 720kg
Optional Devices	1.Lateral feed device, 2.Straight feed device, 3.Belt material conveyor,
	4.End sealing auxiliary conveyor, 5.Auxiliary material feeding device, 6.Materia cut prevent device,
	7.Perforating device, 8.Angle folding device, 9.Date Printer, 10.Labelling machine

Packing type:

1.Sealing type:4 sides sealing;

2.Cutting type:Straight cutting; Zig zag cutting; Round cutting; Irregular
