Automatic Horizontal Flow Wrap Machine

Application:

Suitable for packaging various kinds of regular objects like biscuits, pies , chocolates,bread, instant ,noodles, moon-cakes,drugs, daily applications, industrial parts,paper boxes,tray. etc

Details:

Model: LP-250B/ 350B/ 450B/ 600B/ 700B/ 800B/ 900B

Speed: 20-230 bags/min

Bag Size: L: 65-700mm; W: 30-400mm

Film width: Max.800 mm

Product height: Max.130 mm

Film roll diameter: Max.320mm

Packaging rate: 20-230 bags/min;

Features:

Dual frequency conversion control, Bag length can be set and cut in one step,saving time and film.

Interface features easy and quick setting and operation.

Self failure diagnosis, clear failure display.

High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.

Temperature independent PID control, more suitable for packaging different materials.

Positioned stop function, without sticking knife or wasting film.

Simple driving system, reliable working, convenient maintenance.

All control is realized through software,easy for function adjusting and technical upgrade.

Application:

Suitable for packaging various kinds of regular objects like biscuits, pies , chocolates,bread, instant ,noodles, moon-cakes,drugs, daily applications, industrial parts,paper boxes,tray. etc.

Samples:

Specification:

Model	LP-250B	LP-350B	LP-450B	LP-600B	LP-700B	LP-800B	LP-900B
Film width	Max250mm	Max350mm	Max450mm	Max600mm	Max700mm	Max.800 mm	Max.900mm
Bag length	65-190mm or120-280mm	65-190mm or120-280mm	150-450mm	160-500mm	180-600 mm	210-650mm	240-700mm
Bag width	30-110mm	50-160mm	50-180mm	100-280mm	100-330 mm	120-350mm	150-400mm
Product height	Max.40mm	Max.40mm	Max.75mm	Max.110mm	Max.110 mm	Max.130 mm	Max.150mm
Film roll diameter	Max.320mm
Packaging rate	40-230 bags/min	40-180bags/min	30-150Bags/min	20-150 bags/min	20-130 bags/min	20-120bag/min	20-100 bags/min
Power	220V,50/60Hz,2.4kw	220V,50/60Hz,2.6kw	220V,50/60Hz,2.8kw	220V,50/60Hz,2.8kw	220V,50/60Hz,2.8kw	220V,50/60Hz,4.5kw	220V,50/60Hz,4.5kw
Machine size	（L）3770（W）720（H）1420mm	（L）4030（W）770（H）1420mm	(L)4030(W)820(H)1420mm	(L)4030(W)970(H)1500mm	(L)4030(W)980(L)1500mm	(L)4100(W)1170(H)1550mm	(L)4300(W)1270(H)1550mm
Machine quality	About 500kg	About 580kg	About650kg	About680kg	About720kg	About800kg	About 850kg
Remarks	optional air filling device）/optional angle folding）
Film material）	OPP/ PE/ PVC/ OPP/ CPP/ PT/ PE/ KOP/ CPP/ Aluminum Coating Film/ Aluminum Film

Combined Parts:

1.Belt material conveyor; 2.End sealing drag chain; 3.Auxiliary material feeding device; 4.Material cut prevent device; 5.Perforating device; 6.Angle folding device; 7.Date printer; 8.Labeling machine; 9.Thermal transfer code printer; 10.Air charging system; 11.Cutting stop; 12.Prevent empty package.
