Automatic Granule Snack Food Big Capacity Package Vertical Packing machine

Application:

Automatic granule snack food big capacity package vertical packing machines are used in almost every industry such as snacks, nuts, cookies, popcorn, frozen food, pet food, seeds, beans, jerky, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Optional:
Inquiry
Features:

1.Big capacity packaging machine, up to 35cm* 60cm

2.Two times filling avoiding material get stucked at the mouth of bag former

3.Double film drive for the length, long package

4.SS304 snack packing machine

5.Automatic packing machine
Application:

This vertical weighing popcorn packing machine is suitable for filling all kinds of grain material, sheet material, strip material, and abnormity material, such as popcorn, seeds, sunflower seeds, nuts, candy, chips, peanuts, nutlets, preserved fruit, jelly, biscuit, confect, camphor ball, currant, almond, etc.

It can adopt all type of 3/4 sided seal bag, pillow bag, back sealing bag, etc.
 vertical form fill and seal
Videos Introduction:
Specification:
Model LD-420 LD-520 LD-720 LD-900 LD-1050 LD-1200
Film Thickness 0.04-0.08mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Bag Length 80-300mm 80-350mm 100-500mm 100-600mm 100-800mm 100-1000mm
Bag Width 60-200mm 100-250mm 180-350mm 260-430mm 290-505mm 290-580mm
Film Roll Diameter Max.320mm Max.320mm Max.320mm 400mm 400mm 400mm
Pakaging Rate 5-60bag/min 5-60bag/min 5-55bag/min 5-20bag/min 5-20bag/min 5-20bag/min
Film Width Max.420mm Max.520mm 150-Max.720mm Max.900mm Max.900mm Max.1200mm
Measurement Range 150-1500ml 5-2000ml 4000ml 1-25L 1-25L 1.5L-45L
Optional:

Z type conveyor

10 heads weigher with high weighing accuracy

Main packer

Product outlet conveyor
