Washing Powder Automatic Zipper Pouch Rotary Doypack Packing Machine

Application:

Suitable for powder pre-made bags, vertical bags, zipper bags packaging such as washing powder, flour, seasoning powder, milk powder, curry powder, turmeric powder, etc.

Details:

Model:LD-8200

Packing material:3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc

size:W：70-200

Filling range:10-1000g

Packing speed:40-60bag/min（speed is determined by the product filling quantity）

Average precision:≤ ±1%

Total power:2.5KW

Dimensions:1900mm X 1570mm X 1700mm（L*W*H）

Features:

Wide range of pouches: All kinds of pre-made pouches such as flat and stand-up pouches (with/without zip)

Easy to operate: PLC and color panel, fault indication on the panel.

Easy to adjust: Only about 10 minutes to change different pouches.

Frequency control: Speed can be adjusted by frequency conversion within the range.

Water proof design: The machine surface can be washed down, so easy cleaning and longer useful life.

No pouch/incorrect pouch opening-no fill-no seal, machine alarm.

Machine alarm and stop when the inadequate air pressure.

Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.

Hygienic construction, the product contact parts are adopted sus304 stainless steel.

Imported engineering plastic bearings, no need to oil, no contamination.

Oil-free vacuum pump, avoid the pollution of the production environmental.

Application:

Suitable for packaging of various powders, such as washing powder, flour, coffee powder, milk powder, curry powder, seasoning powder, etc.

Samples:

Specification:

Model	LD-8200/LD-8250
Packing material	3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc
size	W：70-200/100-250
Filling range	10-1000g/20-2500g
Packing speed	40-60bag/min（speed is determined by the product filling quantity）
Average precision	≤ ±1%
Total power	2.5KW
Dimensions	1900mm X 1570mm X 1700mm（LWH）
Work flow	giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product
Main standard parts	1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system

Combined parts:

The elevator

The dose and filling machine

The work platform

The finished product conveyor
